Pix4Dsurvey

Contact for Pricing
SKU: PIX4DSURVEY

Bridge the gap between photogrammetry and CAD


In Stock

FREE SHIPPING ON ALL ORDERS OVER $300

All orders placed before 2pm will be delivered the next day on overnight track and trace courier. Larger items will be sent on a two day service to the South Island. Please note rural addresses (RD) can take 1-3 days longer.


Features

Capture
Capture images or point clouds with a drone or any laser scanner.
When using a drone, automate and optimize your flights with the free Pix4Dcapture mobile app.

Model
Transform your images into digital point clouds, and import them into Pix4Dsurvey.
Work directly with Pix4Dmapper or Pix4Dmatic files, as well as any .las or .laz file.

Vectorize
Generate a TIN to model the ground and create engineering-ready CAD vector files from point cloud data by extracting key elements of your project with Pix4Dsurvey.

Integrate
Open your simplified, accurate data in any CAD or GIS software with custom layers and properties that fit your existing workflow.



Beyond the point

Extract only the most relevant information to speed up and simplify your surveying workflows



Vectorize anything
Use the combined power of images and point clouds to extract key elements from photogrammetry, laser scanning or LiDAR data. Survey curbs, building footprints, walls, catenary curves and more.

Flexible & scalable
Work with small to very large projects. More than one photogrammetry or laser scanning file can be worked on at once, easily.

CAD ready
Include layers and properties for a smooth transition to CAD or GIS and reduce file size when exporting your projects as vector files.



Built-in vectorization tools
Vectorize your project using points, polylines, polygons and catenary curves with just a few clicks.



Create surfaces
Model the ground with a TIN from points and breaklines to represent the topography of your project. Automate the creation of spot elevations and allow drastic simplification of the number of point cloud points.



Unlock more data
Move beyond photogrammetry, yet still work with Pix4D’s rayCloud to access the original images and 3D point clouds simultaneously. Vectorize in 3D, edit in 2D. Even complex objects such as catenaries only visible in images can be surveyed.



Scale up
Pix4Dsurvey can handle billions of points. Work with more than one point cloud file at a time, in the same project.



Integrated solution
Pix4Dsurvey works with your existing workflows. Import .p4d files from Pix4Dmapper at the click of a button, or work with LAS files.



Easy export
Every surveyed object can be assigned to a layer and edited. Layers can be exported separately or together for a smooth transition to your preferred CAD or GIS software.

View Full Feature List



Your choice of point cloud

Import projects from Pix4Dmapper, Pix4Dmatic, or any .las or .laz file.

Aerial data
Create a point cloud from images in Pix4Dmapper or Pix4Dmatic, and drag and drop the .p4d or .p4m file to Pix4Dsurvey.

Laser scanner or LiDAR
Pix4Dsurvey works with any point cloud formatted as a .las or .laz file.



Product Specifications



Inputs

Features

Advantages

Aerial (nadir and oblique) and terrestrial
imagery
Process images taken at any angle and from any aerial manned or unmanned platform as well as from
the ground
Video (mp4 or avi format) Automatically extracts still frames from video files to create a project
Any camera (compact, SLR, thermal,
multispectral, GoPro, 360-degree, largeframe
add-on, etc.) images in .jpg or .tiff
Use images acquired by any camera, from small to large frames, from consumer-grade to highly
specialized cameras
Multi-camera support for the same project Create a project using images from different cameras and process them together
Camera rig support Process images using known rig relatives from multiple synchronized cameras, customized or from
known manufacturers for more robust, accurate and faster processing
Ground control point edit and import Import and edit ground control points to improve the absolute accuracy of your project
Known or custom reference coordinate
system support in imperial or metric units
Select EPSG code from known coordinate systems or define your own local system
Camera exterior orientation support Optimize camera exterior orientation parameters starting from GPS and IMU input parameters
External point cloud import Import a point cloud from different sources, such as LiDAR, and use it to create a DSM and orthomosaic

Processing

Processing templates  Automate processing and generation of outputs by using standard or customized templates
Rapid Check with Quality Report Rapid processing template for a dataset quick check while still on site
Camera self-calibration   Optimize internal camera parameters, such as focal length, principal point of autocollimation and lens distortions
Rolling shutter effect correction  Correct the warp of images taken with rolling shutter cameras (like GoPro, DJI Phantom 2 and 3, etc.)
to maintain good accuracy, especially useful when flying fast and low.
Automatic Aerial Triangulation (AAT) and
Bundle Block Adjustment (BBA)
Process with or without known camera exterior orientations: (x, y, z, omega, phi, kappa)
Automatic point cloud densification  Produce a dense and detailed 3D point cloud, which can be used as a basis for DSM and 3D mesh
Automatic point cloud filtering &
smoothing
Use presets for point cloud filtering and smoothing options
Machine-learning point cloud
classification
Automatically classify the RGB dense point cloud into five groups: ground, road surfaces, high
vegetation, buildings and human-made objects
Automatic DTM/DEM extraction  Remove above-ground objects from DSM and create a bare-Earth model. For additional control, select
and delete points manually in the rayCloud to improve DTM/DEM generation
Automatic brightness and color correction  Compensate automatically for change of brightness, luminosity and color balancing of images
Automatic outlier detection Detect incorrectly-clicked MTPs/GCPs to reduce human errors
Quality Report

Assess the accuracy and quality of projects
Project merging and splitting Combine multiple projects into one or split large projects into several for more efficient processing
Project area definition

Import (.shp) or draw specific areas to faster generate results inside specific boundaries
Targeted Feature Extraction Give the number of features to find, getting more features in low-texture images to assist the
reconstruction or less features for large-frame images to speed up processing
Multiprocessor CPU + GPU support  Increase the processing speed by leveraging the power of CPU cores and threads, as well as GPUs
Raycloud Editor Project visualization

Assess quality of optimized camera positions, 3D point cloud and mesh
Navigation modes  View 3D point cloud and mesh in standard, trackball, or first person viewing modes
Scale Constraint

 Accurately scale projects with no or imprecise geolocation by defining one/multiple distances
Orientation Constraint  Orientate projects with no or imprecise geolocation by defining directions of one/multiple axes
Ground control point (GCP ) /
Manual tie point (MTP) editing
Annotate and edit 2D and 3D ground control points (GCPs), check points and manual tie points with the highest accuracy, using both original images and 3D information at the same time
Project reoptimization Reoptimize camera positions and/or rematch images based on GCPs and manual tie points to improve
reconstruction of difficult areas
Image masking Carve: Remove points from 3D point cloud and create filters based on image content.
Mask: Clear the unwanted background in orthoplane results.
Global Mask: Disregard objects which appear in all images, such as a drone leg or tripod which occluded the
lens during all image acquisition.
Point cloud editing

Select, classify or delete points from the point cloud using various selection tools
Orthoplane creation  Define a plane to generate a DSM and orthomosaic from building facades, bridge piles, etc
Polyline and surface object creation  Annotate and measure polylines and surfaces in the point cloud.
Accurately refine vertexes in multiple original images.
3D mesh and DSM editing Annotate and create surfaces in the point cloud to flatten an area, or to fill up holes in the mesh
and DSM caused by insufficient image content.
Fly-through animation  Create a virtual camera trajectory in 3D rayCloud viewer, play the animation in real-time, export the
animation as a video (in mp4 and avi format) and the editable flightpath waypoints in .csv format
Volume Manager Volume object creation   Annotate and measure volumes based on the DSM
Volume object management  Import and export selected volume bases in .shp files to enable easy monitoring of stockpiles on site.
Base adjustment  Adjust the reference base to fit different terrain and obtain accurate measurement
Mosaic Editor Region editing


Create and edit regions on the orthomosaic, choose the best content from multiple underlying
images and projection type to remove moving objects or artifacts
Local blending  Edit only the desired portion of the orthomosaic, blend it in real-time and get the improved
orthomosaic within minutes
Planar or ortho projection selection Select planar or ortho projection for each created region to remove artifacts
Index Calculator Reflectance map

Generate an accurate Reflectance map at the preferred resolution as a basis of index maps target
Radiometric adjustment interface  Make the reflectance maps more reliable and accurate by correcting illumination effects using a
radiometric
Multiple region management

Improve your analysis by managing and visualizing index values per region
Automatic NDVI map  Generate singleband and NDVI maps based on pre-defined formulas without user intervention
Index formula editing

Create and save your own formulas choosing among each available input band and generate custom
index maps
Class management Create a basis of your annotated vector map by segmenting the data into classes using statistical algorithms
(equal spacing, equal area, Jenks)
Prescription annotation

Match on-site scouts and observations by assigning annotations based on your decisions
Prescription map export Put your data into action and export the prescription map in .shp format

In the box
