CZI IR10 Infrared Laser Zoom Spotlight

Contact for Pricing
SKU: IR10

The IR10 provides supplementary infrared light using a fiber laser light source which is able to illuminate a subject up to 3,000 feet in distance. Compatible with both the DJI Matrice 300 and Matrice 200 Series V2 aircrafts.


FREE SHIPPING ON ALL ORDERS OVER $300

All orders placed before 2pm will be delivered the next day on overnight track and trace courier. Larger items will be sent on a two day service to the South Island. Please note rural addresses (RD) can take 1-3 days longer.


Features

The IR10 Infrared Zoom Spotlight is for the DJI Matrice 300 and Matrice 200 Series V2 and provides a 3,000 foot range of infrared supplementary light by leveraging the latest fiber laser technology. The IR10 is used complementary with camera payloads that have IR cut and night scene functionality, this includes the Zenmuse H20T & H20 and Zenmuse Z30. With gimbal sync and its stabilized gimbal system, the IR10 moves cohesively with your primary payload operation

The IR10 is designed for law enforcement and search & rescue by assisting in operations where infrared technology (invisible to the human eye) enables excellent insight in dark conditions. The IR10's adjustable zoom/beam is capable of a 70X optical zoom.

Read the user manual here

Product Specifications

Model: IR10
Electrical Interface: DJI SkyPort V2.0
Weight: 800G
Power: 40W
Optical Power: 12W
FOV: 0.56-45°
Light Wavelength: 808 nm

In the box

Cytop IR10 Infrared Laser x 1

WHY BUY FROM US?

By buying from Ferntech, you'll have the confidence that you are dealing directly with New Zealand's leading drone experts. Our staff are knowledgable drone pilots who offer expert advice, trusted support and superior specialist service. Only through us will you receive a full New Zealand warranty, phone and email support, and access to our certified Repairs Centre with DJI-qualified drone technicians. And we guarantee that we will have the best prices on the market — if not let us know and we will match any price (conditions apply).



Warranty Details

General

Which platform does Z15 support?

Support M200 V1 series and M200 V2 series;

How to install Z15 to the drone?

Z15 is designed based on the DJI SKYPORT and can be directly installed to the M200 drone,
the same steps as installing DJI Zenmuse camera;

How to install Z15 to the M210 dual downward gimbal slot?

If Z15 is used with ZENMUSE X5S/X7/XT2, please install Z15 to II position gimbal slot; If the Z15 is used alone, please install the Z15 to I position gimbal slot;

Does Z15 support the M210 V1 dual Downward Gimbals?

The M210 V1 dual Downward Gimbals function needs to update the drone firmware to the latest;

Does Z15 support DJI PILOT?

Yes, DJI PILOT officially supports natively, no need to install third-party application APP;

What are the characteristics of Z15 compared to the M2E spotlight?

Z15 has a 3-axis gimbal for flexible adjustment of the lighting angle; Using 4 high-power Cree lamp beads, power up to 68W, luminous flux up to 10200lm; Supporting dual Downward



Gimbals with DJI Zenmuse camera

What is the actual lighting effect of Z15?

Under the overhead light of 120 meters, the ground staff can read the newspaper;

What is the area illuminated by Z15 at different flight altitudes?

At an altitude of 120 meters, the area illuminated by the ground is 1863 m2, which is equivalent to the area of 5 standard basketball courts; At an altitude of 50 meters, the area illuminated by the ground is 323 m2, which is equivalent to a standard basketball court area;

Is Z15 spotlight harmful to the human eye?

Please don't illuminate the human eye
