Share UAV PSDK 102S V3 - 5 Camera Oblique Mapping

Contact for Pricing
SKU: PSDK102SV3

5 Lens Oblique Camera with 3-Axis Stabilised Gimbal


  • Free Shipping on all orders over $300
  • Order before 2.00pm for same day dispatch
  • Click & collect from our Auckland store
  • Local warranty, support and repairs

Features

Stabilised 3-Axis Gimbal

The intelligent 3-axis gimbal ensures that the camera remains stable during missions, effectively eliminating any distortion caused by camera shake. With 180° rotation capabilities, data can be captured from any angle, enabling facade photogrammetry and breaking through the traditional limitations of data capture angles.



Self-Designed Mapping Camera Sensor

The PSDK 102S V3 surveying camera features the SHARE self-designed S-OPG Mapping Sensor, which integrates data imaging, parameter settings, POS data writing, and dynamic image transmission. Along with the self-designed S-ML mapping lens, which supports a short focus distance of 12m, the camera is highly adaptable to a variety of environments and use cases.



Instant POS Data Writing in Captured Images

The TimeSync 2.0 algorithm ensures that the camera aligns with the drone's POS data at a microsecond level. Surveyors can save time on POS processing after the mission, without worrying about data accuracy.



A Versatile and Reliable All-Rounder

As a DJI Enterprise partner, Share UAV have developed a range of solutions that work seamlessly with the DJI M300. Surveyors can use this combination to carry out missions in various applications, including micro-photogrammetry, terrain-following mapping, and 2D & 3D mapping.


Applications

3D Mapping - City 3D mapping; Urban planning; 3D gamin-scene building; Large-scale cadastral surveying
Close-Proximity Surveying - As-built surveys; Digital archeology and preservation of cultural heritage; Property digitalisation
Terrain Following Surveying - Mountain topo surveying; high-drop terrain surveying, natural resources management

Product Specifications

Dimension: 171 × 192 × 185 mm
Lens Focal Length: orthographic 25mm oblique 35mm
Camera Sensor: APS-C
Storage: 1280GB
Weight: 1100g (with gimbal)
Pixels: 125MP
Resolution: 6144X4096
Shooting Interval: ≥0.55
Aparture Size: F5.6
Data Copying: USB 3.0 interface, Type-C Cable
Power Supply: External power supply with DC 12-48V

In the box

Share UAV PSDK 102S V3 - 5 Camera Oblique Mapping × 1
